MLflow Models
An MLflow Model is a standard format for packaging machine learning models that can be used in a variety of downstream tools---for example, real-time serving through a REST API or batch inference on Apache Spark. The format defines a convention that lets you save a model in different "flavors" that can be understood by different downstream tools.
Storage Format
Each MLflow Model is a directory containing arbitrary files, together with an MLmodel
file in the root of the directory that can define multiple flavors that the model can be viewed
in.
The model aspect of the MLflow Model can either be a serialized object (e.g., a pickled scikit-learn
model)
or a Python script (or notebook, if running in Databricks) that contains the model instance that has been defined
with the mlflow.models.set_model()
API.
Flavors are the key concept that makes MLflow Models powerful: they are a convention that deployment
tools can use to understand the model, which makes it possible to write tools that work with models
from any ML library without having to integrate each tool with each library. MLflow defines
several "standard" flavors that all of its built-in deployment tools support, such as a "Python
function" flavor that describes how to run the model as a Python function. However, libraries can
also define and use other flavors. For example, MLflow's mlflow.sklearn
library allows loading models back as a scikit-learn Pipeline
object for use in code that is aware of
scikit-learn, or as a generic Python function for use in tools that just need to apply the model
(for example, the mlflow deployments
tool with the option -t sagemaker
for deploying models
to Amazon SageMaker).
MLmodel file
All of the flavors that a particular model supports are defined in its MLmodel
file in YAML
format. For example, running python examples/sklearn_logistic_regression/train.py
from within the
MLflow repo
will create the following files under the model
directory:
# Directory written by mlflow.sklearn.save_model(model, "model", input_example=...)
model/
├── MLmodel
├── model.pkl
├── conda.yaml
├── python_env.yaml
├── requirements.txt
├── input_example.json (optional, only logged when input example is provided and valid during model logging)
├── serving_input_example.json (optional, only logged when input example is provided and valid during model logging)
└── environment_variables.txt (optional, only logged when environment variables are used during model inference)
And its MLmodel
file describes two flavors:
time_created: 2018-05-25T17:28:53.35
flavors:
sklearn:
sklearn_version: 0.19.1
pickled_model: model.pkl
python_function:
loader_module: mlflow.sklearn
Apart from a flavors field listing the model flavors, the MLmodel YAML format can contain the following fields:
time_created
: Date and time when the model was created, in UTC ISO 8601 format.run_id
: ID of the run that created the model, if the model was saved using tracking.signature
: model signature in JSON format.input_example
: reference to an artifact with input example.databricks_runtime
: Databricks runtime version and type, if the model was trained in a Databricks notebook or job.mlflow_version
: The version of MLflow that was used to log the model.
Additional Logged Files
For environment recreation, we automatically log conda.yaml
, python_env.yaml
, and requirements.txt
files whenever a model is logged.
These files can then be used to reinstall dependencies using conda
or virtualenv
with pip
. Please see
How MLflow Model Records Dependencies for more details about these files.
If a model input example is provided when logging the model, two additional files input_example.json
and serving_input_example.json
are logged.
See Model Input Example for more details.
When logging a model, model metadata files (MLmodel
, conda.yaml
, python_env.yaml
, requirements.txt
) are copied to a subdirectory named metadata
.
For wheeled models, original_requirements.txt
file is also copied.
When a model registered in the MLflow Model Registry is downloaded, a YAML file named
registered_model_meta
is added to the model directory on the downloader's side.
This file contains the name and version of the model referenced in the MLflow Model Registry,
and will be used for deployment and other purposes.
If you log a model within Databricks, MLflow also creates a metadata
subdirectory within
the model directory. This subdirectory contains the lightweight copy of aforementioned
metadata files for internal use.
Environment variables file
MLflow records the environment variables that are used during model inference in environment_variables.txt
file when logging a model.
environment_variables.txt
file only contains names of the environment variables that are used during
model inference, values are not stored.
Currently MLflow only logs the environment variables whose name contains any of the following keywords:
RECORD_ENV_VAR_ALLOWLIST = {
# api key related
"API_KEY", # e.g. OPENAI_API_KEY
"API_TOKEN",
# databricks auth related
"DATABRICKS_HOST",
"DATABRICKS_USERNAME",
"DATABRICKS_PASSWORD",
"DATABRICKS_TOKEN",
"DATABRICKS_INSECURE",
"DATABRICKS_CLIENT_ID",
"DATABRICKS_CLIENT_SECRET",
"_DATABRICKS_WORKSPACE_HOST",
"_DATABRICKS_WORKSPACE_ID",
}
Example of a pyfunc model that uses environment variables:
import mlflow
import os
os.environ["TEST_API_KEY"] = "test_api_key"
class MyModel(mlflow.pyfunc.PythonModel):
def predict(self, context, model_input, params=None):
if os.environ.get("TEST_API_KEY"):
return model_input
raise Exception("API key not found")
with mlflow.start_run():
model_info = mlflow.pyfunc.log_model(
name="model", python_model=MyModel(), input_example="data"
)
Environment variable TEST_API_KEY
is logged in the environment_variables.txt file like below
# This file records environment variable names that are used during model inference.
# They might need to be set when creating a serving endpoint from this model.
# Note: it is not guaranteed that all environment variables listed here are required
TEST_API_KEY
Before you deploy a model to a serving endpoint, review the environment_variables.txt file to ensure all necessary environment variables for model inference are set. Note that not all environment variables listed in the file are always required for model inference. For detailed instructions on setting environment variables on a databricks serving endpoint, refer to this guidance.
To disable this feature, set the environment variable MLFLOW_RECORD_ENV_VARS_IN_MODEL_LOGGING
to false
.
Managing Model Dependencies
An MLflow Model infers dependencies required for the model flavor and automatically logs them. However, it also allows you to define extra dependencies or custom Python code, and offer a tool to validate them in a sandbox environment. Please refer to Managing Dependencies in MLflow Models for more details.
Model Signatures And Input Examples
In MLflow, understanding the intricacies of model signatures and input examples is crucial for effective model management and deployment.
- Model Signature: Defines the schema for model inputs, outputs, and additional inference parameters, promoting a standardized interface for model interaction.
- Model Input Example: Provides a concrete instance of valid model input, aiding in understanding and testing model requirements. Additionally, if an input example is provided when logging a model, a model signature will be automatically inferred and stored if not explicitly provided.
- Model Serving Payload Example: Provides a json payload example for querying a deployed model endpoint.
If an input example is provided when logging a model, a serving payload example is automatically generated
from the input example and saved as
serving_input_example.json
.
Our documentation delves into several key areas:
- Supported Signature Types: We cover the different data types that are supported, such as tabular data for traditional machine learning models and tensors for deep learning models.
- Signature Enforcement: Discusses how MLflow enforces schema compliance, ensuring that the provided inputs match the model's expectations.
- Logging Models with Signatures: Guides on how to incorporate signatures when logging models, enhancing clarity and reliability in model operations.
For a detailed exploration of these concepts, including examples and best practices, visit the Model Signatures and Examples Guide. If you would like to see signature enforcement in action, see the notebook tutorial on Model Signatures to learn more.
Model API
You can save and load MLflow Models in multiple ways. First, MLflow includes integrations with several common libraries. For example, mlflow.sklearn contains save_model, log_model, and load_model functions for scikit-learn models. Second, you can use the mlflow.models.Model class to create and write models. This class has four key functions:
- add_flavor to add a flavor to the model. Each flavor has a string name and a dictionary of key-value attributes, where the values can be any object that can be serialized to YAML.
- save to save the model to a local directory.
- log to log the model as an artifact in the current run using MLflow Tracking.
- load to load a model from a local directory or from an artifact in a previous run.
Models From Code
To learn more about the Models From Code feature, please visit the deep dive guide for more in-depth explanation and to see additional examples.
The Models from Code feature is available in MLflow versions 2.12.2 and later. This feature is experimental and may change in future releases.
The Models from Code feature allows you to define and log models directly from a stand-alone python script. This feature is particularly useful when you want to
log models that can be effectively stored as a code representation (models that do not need optimized weights through training) or applications
that rely on external services (e.g., LangChain chains). Another benefit is that this approach entirely bypasses the use of the pickle
or
cloudpickle
modules within Python, which can carry security risks when loading untrusted models.
This feature is only supported for LangChain, LlamaIndex, and PythonModel models.
In order to log a model from code, you can leverage the mlflow.models.set_model()
API. This API allows you to define a model by specifying
an instance of the model class directly within the file where the model is defined. When logging such a model, a
file path is specified (instead of an object) that points to the Python file containing both the model class definition and the usage of the
set_model
API applied on an instance of your custom model.
The figure below provides a comparison of the standard model logging process and the Models from Code feature for models that are eligible to be saved using the Models from Code feature:
For example, defining a model in a separate file named my_model.py
:
import mlflow
from mlflow.models import set_model
class MyModel(mlflow.pyfunc.PythonModel):
def predict(self, context, model_input):
return model_input
# Define the custom PythonModel instance that will be used for inference
set_model(MyModel())
The Models from code feature does not support capturing import statements that are from external file references. If you have dependencies that
are not captured via a pip
install, dependencies will need to be included and resolved via appropriate absolute path import references from
using the code_paths feature.
For simplicity's sake, it is recommended to encapsulate all of your required local dependencies for a model defined from code within the same
python script file due to limitations around code_paths
dependency pathing resolution.
When defining a model from code and using the mlflow.models.set_model()
API, the code that is defined in the script that is being logged
will be executed internally to ensure that it is valid code. If you have connections to external services within your script (e.g. you are connecting
to a GenAI service within LangChain), be aware that you will incur a connection request to that service when the model is being logged.
Then, logging the model from the file path in a different python script:
import mlflow
model_path = "my_model.py"
with mlflow.start_run():
model_info = mlflow.pyfunc.log_model(
python_model=model_path, # Define the model as the path to the Python file
name="my_model",
)
# Loading the model behaves exactly as if an instance of MyModel had been logged
my_model = mlflow.pyfunc.load_model(model_info.model_uri)
The mlflow.models.set_model()
API is not threadsafe. Do not attempt to use this feature if you are logging models concurrently
from multiple threads. This fluent API utilizes a global active model state that has no consistency guarantees. If you are interested in threadsafe
logging APIs, please use the mlflow.client.MlflowClient APIs for logging models.
Built-In Model Flavors
MLflow provides several standard flavors that might be useful in your applications. Specifically, many of its deployment tools support these flavors, so you can export your own model in one of these flavors to benefit from all these tools:
- Python Function (
python_function
) - R Function (
crate
) - H2O (
h2o
) - Keras (
keras
) - PyTorch (
pytorch
) - Scikit-learn (
sklearn
) - Spark MLlib (
spark
) - TensorFlow (
tensorflow
) - ONNX (
onnx
) - XGBoost (
xgboost
) - LightGBM (
lightgbm
) - CatBoost (
catboost
) - Spacy(
spaCy
) - Statsmodels (
statsmodels
) - Prophet (
prophet
) - Pmdarima (
pmdarima
) - John Snow Labs (
johnsnowlabs
) - Diviner (
diviner
) - Transformers (
transformers
) - SentenceTransformers (
sentence_transformers
)
Python Function (python_function
)
The python_function
model flavor serves as a default model interface for MLflow Python models.
Any MLflow Python model is expected to be loadable as a python_function
model. This enables
other MLflow tools to work with any python model regardless of which persistence module or
framework was used to produce the model. This interoperability is very powerful because it allows
any Python model to be productionized in a variety of environments.
In addition, the python_function
model flavor defines a generic
filesystem model format
for Python models and provides utilities for saving and loading models
to and from this format. The format is self-contained in the sense that it includes all the
information necessary to load and use a model. Dependencies are stored either directly with the
model or referenced via conda environment. This model format allows other tools to integrate
their models with MLflow.
How To Save Model As Python Function
Most python_function
models are saved as part of other model flavors - for example, all mlflow
built-in flavors include the python_function
flavor in the exported models. In addition,
the mlflow.pyfunc module defines functions for creating python_function
models explicitly.
This module also includes utilities for creating custom Python models, which is a convenient way of
adding custom python code to ML models. For more information, see the custom Python models
documentation.
For information on how to store a custom model from a python script (models from code functionality), see the guide to models from code for the recommended approaches.
How To Load And Score Python Function Models
Loading Models
You can load python_function
models in Python by using the mlflow.pyfunc.load_model()
function. It is important
to note that load_model
assumes all dependencies are already available and will not perform any checks or installations
of dependencies. For deployment options that handle dependencies, refer to the model deployment section.
Scoring Models
Once a model is loaded, it can be scored in two primary ways:
-
Synchronous Scoring The standard method for scoring is using the
predict
method, which supports various input types and returns a scalar or collection based on the input data. The method signature is:predict(data: Union[pandas.Series, pandas.DataFrame, numpy.ndarray, csc_matrix, csr_matrix, List[Any], Dict[str, Any], str],
params: Optional[Dict[str, Any]] = None) → Union[pandas.Series, pandas.DataFrame, numpy.ndarray, list, str] -
Synchronous Streaming Scoring
notepredict_stream
is a new interface that was added to MLflow in the 2.12.2 release. Previous versions of MLflow will not support this interface. In order to utilizepredict_stream
in a custom Python Function Model, you must implement thepredict_stream
method in your model class and return a generator type.For models that support streaming data processing, predict_stream method is available. This method returns a
generator
, which yields a stream of responses, allowing for efficient processing of large datasets or continuous data streams. Note that thepredict_stream
method is not available for all model types. The usage involves iterating over the generator to consume the responses:predict_stream(data: Any, params: Optional[Dict[str, Any]] = None) → GeneratorType
Demonstrating predict_stream()
Below is an example demonstrating how to define, save, load, and use a streamable model with the predict_stream()
method:
import mlflow
import os
# Define a custom model that supports streaming
class StreamableModel(mlflow.pyfunc.PythonModel):
def predict(self, context, model_input, params=None):
# Regular predict method implementation (optional for this demo)
return "regular-predict-output"
def predict_stream(self, context, model_input, params=None):
# Yielding elements one at a time
for element in ["a", "b", "c", "d", "e"]:
yield element
# Save the model to a directory
tmp_path = "/tmp/test_model"
pyfunc_model_path = os.path.join(tmp_path, "pyfunc_model")
python_model = StreamableModel()
mlflow.pyfunc.save_model(path=pyfunc_model_path, python_model=python_model)
# Load the model
loaded_pyfunc_model = mlflow.pyfunc.load_model(model_uri=pyfunc_model_path)
# Use predict_stream to get a generator
stream_output = loaded_pyfunc_model.predict_stream("single-input")
# Consuming the generator using next
print(next(stream_output)) # Output: 'a'
print(next(stream_output)) # Output: 'b'
# Alternatively, consuming the generator using a for-loop
for response in stream_output:
print(response) # This will print 'c', 'd', 'e'
Python Function Model Interfaces
All PyFunc models will support pandas.DataFrame
as an input. In addition to pandas.DataFrame
,
DL PyFunc models will also support tensor inputs in the form of numpy.ndarrays
. To verify
whether a model flavor supports tensor inputs, please check the flavor's documentation.
For models with a column-based schema, inputs are typically provided in the form of a pandas.DataFrame
.
If a dictionary mapping column name to values is provided as input for schemas with named columns or if a
python List
or a numpy.ndarray
is provided as input for schemas with unnamed columns, MLflow will cast the
input to a DataFrame. Schema enforcement and casting with respect to the expected data types is performed against
the DataFrame.
For models with a tensor-based schema, inputs are typically provided in the form of a numpy.ndarray
or a
dictionary mapping the tensor name to its np.ndarray value. Schema enforcement will check the provided input's
shape and type against the shape and type specified in the model's schema and throw an error if they do not match.
For models where no schema is defined, no changes to the model inputs and outputs are made. MLflow will propagate any errors raised by the model if the model does not accept the provided input type.
The python environment that a PyFunc model is loaded into for prediction or inference may differ from the environment
in which it was trained. In the case of an environment mismatch, a warning message will be printed when
calling mlflow.pyfunc.load_model()
. This warning statement will identify the packages that have a version mismatch
between those used during training and the current environment. In order to get the full dependencies of the
environment in which the model was trained, you can call mlflow.pyfunc.get_model_dependencies()
.
Furthermore, if you want to run model inference in the same environment used in model training, you can
call mlflow.pyfunc.spark_udf()
with the env_manager
argument set as "conda". This will generate the environment
from the conda.yaml
file, ensuring that the python UDF will execute with the exact package versions that were used
during training.
Some PyFunc models may accept model load configuration, which controls how the model is loaded and predictions computed. You can learn which configuration the model supports by inspecting the model's flavor metadata:
model_info = mlflow.models.get_model_info(model_uri)
model_info.flavors[mlflow.pyfunc.FLAVOR_NAME][mlflow.pyfunc.MODEL_CONFIG]
Alternatively, you can load the PyFunc model and inspect the model_config
property:
pyfunc_model = mlflow.pyfunc.load_model(model_uri)
pyfunc_model.model_config
Model configuration can be changed at loading time by indicating model_config
parameter in
the mlflow.pyfunc.load_model()
method:
pyfunc_model = mlflow.pyfunc.load_model(model_uri, model_config=dict(temperature=0.93))
When a model configuration value is changed, those values the configuration the model was saved with. Indicating an invalid model configuration key for a model results in that configuration being ignored. A warning is displayed mentioning the ignored entries.
Model configuration vs parameters with default values in signatures: Use model configuration when you need to provide
model publishers for a way to change how the model is loaded into memory and how predictions are computed for all the
samples. For instance, a key like user_gpu
. Model consumers are not able to change those values at predict time. Use
parameters with default values in the signature to provide a users the ability to change how predictions are computed on
each data sample.
R Function (crate
)
The crate
model flavor defines a generic model format for representing an arbitrary R prediction
function as an MLflow model using the crate
function from the
carrier package. The prediction function is expected to take a dataframe as input and
produce a dataframe, a vector or a list with the predictions as output.
This flavor requires R to be installed in order to be used.
crate
usage
For a minimal crate model, an example configuration for the predict function is:
library(mlflow)
library(carrier)
# Load iris dataset
data("iris")
# Learn simple linear regression model
model <- lm(Sepal.Width~Sepal.Length, data = iris)
# Define a crate model
# call package functions with an explicit :: namespace.
crate_model <- crate(
function(new_obs) stats::predict(model, data.frame("Sepal.Length" = new_obs)),
model = model
)
# log the model
model_path <- mlflow_log_model(model = crate_model, artifact_path = "iris_prediction")
# load the logged model and make a prediction
model_uri <- paste0(mlflow_get_run()$artifact_uri, "/iris_prediction")
mlflow_model <- mlflow_load_model(model_uri = model_uri,
flavor = NULL,
client = mlflow_client())
prediction <- mlflow_predict(model = mlflow_model, data = 5)
print(prediction)
H2O (h2o
)
The h2o
model flavor enables logging and loading H2O models.
The mlflow.h2o module defines save_model()
and log_model() methods in python,
and mlflow_save_model
and mlflow_log_model in R for saving H2O
models in MLflow Model format. These methods produce MLflow Models with the python_function
flavor, allowing you to load them
as generic Python functions for inference via mlflow.pyfunc.load_model()
.
This loaded PyFunc model can be scored with only DataFrame input. When you load
MLflow Models with the h2o
flavor using mlflow.pyfunc.load_model()
,
the h2o.init() method is
called. Therefore, the correct version of h2o(-py)
must be installed in the loader's
environment. You can customize the arguments given to
h2o.init() by modifying the
init
entry of the persisted H2O model's YAML configuration file: model.h2o/h2o.yaml
.
Finally, you can use the mlflow.h2o.load_model()
method to load MLflow Models with the
h2o
flavor as H2O model objects.
For more information, see mlflow.h2o.
